We got Your Steam Boiler

Whether oil, gas, electric, or hybrid, a JUMAG steam generator is always the right choice. It is also economical, fail-safe, and climate-efficient.

GET DIRECT ADVICE

Oil / Gas Steam Generator

Touchscreen control in many languages
Robust evaporation system (no coil)
Exhaust gas heat exchanger
Centrifugal pump integrated in the control cabinet (no piston pump)
Stepless, intelligent water level control

Containerdampfanlage

Electric heating (thermostat-controlled)
Fresh air fan with electrically controlled air flap
Sub-distribution Emergency stop button recessed on the outside of the container (no protruding parts on the container)
1 x 230 V service socket
Interior lighting
Exterior paint finish in RAL colors according to customer requirements

Compact Steam System

All components required for steam generation, such as steam generator with economizer, feed water tank, metering pump, and blowdown tank, are mounted on a frame to save space.
Despite its compact design, it is easily accessible for maintenance.
Also available as a multiple steam system.
Flexible as an oil- or gas-fired system or in hybrid operation with electrically powered steam generators.

Multiple Steam System

Space-saving installation
Optional: Prepared for system expansion in case higher steam outputs are required in the future
Compact solution ensures optimal utilization; individual steam generators switch on and off depending on steam demand.
Fail-safe operation thanks to redundancy (in case of boiler malfunction or maintenance)

Electric Steam Generator

Touchscreen control in many languages
Evaporation system and housing cladding made of 1.4571 stainless steel
Dry steam thanks to large water surface and innovative design
Easy access for maintenance
High-temperature-resistant heating rods made of high-alloy stainless steel, with only 10.7 W/cm2
Water level control via modern vibration limiters

“The JUMAG steam boiler has made my life as a brewer easier and given me greater flexibility.”

Thomas Wacho

Brewer at Häffner Bräu GmbH

“Our JUMAG solution is ideal for medium-sized companies that have low steam consumption in their production processes.”

Sabastian Schliebe

Plant manager at Delitzscher Schokoladenfabrik GmbH

“We had previously been equipped with different steam equipment, but needed new equipment. On the recommendation of our distillation equipment supplier, we ultimately decided on JUMAG.”

Nicolas Lombard

Managing Director of the Nussbaumer distillery

“Since our old boiler was getting on in years, we opted for two JUMAG DG 560 units, which have been providing us with a reliable supply of steam ever since.”

Dirk Petri

Managing Director of Textilservice Petri GmbH

What sets JUMAG apart

OVER 60 YEARS
OF EXPERIENCE

MADE IN BADEN-
WÜRTTEMBERG
(LÄNDLE)

NUMEROUS
PATENTS

OWNER-
MANAGED

ROBUST & LOW-MAINTENANCE
DEVICES

OIL, GAS, ELECTRIC,
HYBRID

ENERGY EFFICIENT &
ECONOMICAL

RENT OR
BUY

Robust and low maintenance

High quality and great operational reliability thanks to the compact overall design with industry-standard components.

Energy efficient and economical

High cost-effectiveness of steam boilers thanks to high efficiency and the option of replacing the burner at a later date (oil/gas conversion).

User-friendly

No permits or monitoring required in many countries, and easy to use thanks to self-explanatory full-text touchscreen controls in many languages.

Facts and figures about our steam generators

GDPR 2014/68/EU Category III

PS * V < 1.000

PS * V < 3.000

Steam output up to

160 kg/h (2,6 kg/Min.)

260 kg/h (4,3 kg/Min.)

360 kg/h (6,0 kg/Min.)

460 kg/h (7,6 kg/Min.)

560 kg/h (9,3 kg/Min.)

1060 kg/h (17,7 kg/Min)

Heat Output

105 kW

170 kW

235 kW

300 kW

380 kW

720 kW

Maximum operating pressure

13 barÜ (safety valve blow-off pressure)

Working Pressure

6 to 11 barÜ (lower pressures possible via JUMAG pressure reducing station)

Heat Up Time

approx. 5 min

approx. 8 Min

approx. 10 Min
